| #define | _OHCI_MAKE32(x) ((uint32_t)(x)) |
| |
| #define | _OHCI_MAKEMASK1(n) (_OHCI_MAKE32(1) << _OHCI_MAKE32(n)) |
| |
| #define | _OHCI_MAKEMASK(v, n) (_OHCI_MAKE32((_OHCI_MAKE32(1)<<(v))-1) << _OHCI_MAKE32(n)) |
| |
| #define | _OHCI_MAKEVALUE(v, n) (_OHCI_MAKE32(v) << _OHCI_MAKE32(n)) |
| |
| #define | _OHCI_GETVALUE(v, n, m) ((_OHCI_MAKE32(v) & _OHCI_MAKE32(m)) >> _OHCI_MAKE32(n)) |
| |
| #define | OHCI_ED_ALIGN 32 |
| |
| #define | S_OHCI_ED_FA 0 |
| |
| #define | M_OHCI_ED_FA _OHCI_MAKEMASK(7,S_OHCI_ED_FA) |
| |
| #define | V_OHCI_ED_FA(x) _OHCI_MAKEVALUE(x,S_OHCI_ED_FA) |
| |
| #define | G_OHCI_ED_FA(x) _OHCI_GETVALUE(x,S_OHCI_ED_FA,M_OHCI_ED_FA) |
| |
| #define | S_OHCI_ED_EN 7 |
| |
| #define | M_OHCI_ED_EN _OHCI_MAKEMASK(4,S_OHCI_ED_EN) |
| |
| #define | V_OHCI_ED_EN(x) _OHCI_MAKEVALUE(x,S_OHCI_ED_EN) |
| |
| #define | G_OHCI_ED_EN(x) _OHCI_GETVALUE(x,S_OHCI_ED_EN,M_OHCI_ED_EN) |
| |
| #define | S_OHCI_ED_DIR 11 |
| |
| #define | M_OHCI_ED_DIR _OHCI_MAKEMASK(2,S_OHCI_ED_DIR) |
| |
| #define | V_OHCI_ED_DIR(x) _OHCI_MAKEVALUE(x,S_OHCI_ED_DIR) |
| |
| #define | G_OHCI_ED_DIR(x) _OHCI_GETVALUE(x,S_OHCI_ED_DIR,M_OHCI_ED_DIR) |
| |
| #define | K_OHCI_ED_DIR_FROMTD 0 |
| |
| #define | K_OHCI_ED_DIR_OUT 1 |
| |
| #define | K_OHCI_ED_DIR_IN 2 |
| |
| #define | M_OHCI_ED_LOWSPEED _OHCI_MAKEMASK1(13) |
| |
| #define | M_OHCI_ED_SKIP _OHCI_MAKEMASK1(14) |
| |
| #define | M_OHCI_ED_ISOCFMT _OHCI_MAKEMASK1(15) |
| |
| #define | S_OHCI_ED_MPS 16 |
| |
| #define | M_OHCI_ED_MPS _OHCI_MAKEMASK(11,S_OHCI_ED_MPS) |
| |
| #define | V_OHCI_ED_MPS(x) _OHCI_MAKEVALUE(x,S_OHCI_ED_MPS) |
| |
| #define | G_OHCI_ED_MPS(x) _OHCI_GETVALUE(x,S_OHCI_ED_MPS,M_OHCI_ED_MPS) |
| |
| #define | M_OHCI_ED_PTRMASK 0xFFFFFFF0 |
| |
| #define | M_OHCI_ED_HALT _OHCI_MAKEMASK1(0) |
| |
| #define | M_OHCI_ED_TOGGLECARRY _OHCI_MAKEMASK1(1) |
| |
| #define | OHCI_TD_ALIGN 32 |
| |
| #define | M_OHCI_TD_SHORTOK _OHCI_MAKEMASK1(18) |
| |
| #define | S_OHCI_TD_PID 19 |
| |
| #define | M_OHCI_TD_PID _OHCI_MAKEMASK(2,S_OHCI_TD_PID) |
| |
| #define | V_OHCI_TD_PID(x) _OHCI_MAKEVALUE(x,S_OHCI_TD_PID) |
| |
| #define | G_OHCI_TD_PID(x) _OHCI_GETVALUE(x,S_OHCI_TD_PID,M_OHCI_TD_PID) |
| |
| #define | K_OHCI_TD_SETUP 0 |
| |
| #define | K_OHCI_TD_OUT 1 |
| |
| #define | K_OHCI_TD_IN 2 |
| |
| #define | K_OHCI_TD_RESERVED 3 |
| |
| #define | V_OHCI_TD_SETUP V_OHCI_TD_PID(K_OHCI_TD_SETUP) |
| |
| #define | V_OHCI_TD_OUT V_OHCI_TD_PID(K_OHCI_TD_OUT) |
| |
| #define | V_OHCI_TD_IN V_OHCI_TD_PID(K_OHCI_TD_IN) |
| |
| #define | V_OHCI_TD_RESERVED V_OHCI_TD_PID(K_OHCI_TD_RESERVED) |
| |
| #define | S_OHCI_TD_DI 21 |
| |
| #define | M_OHCI_TD_DI _OHCI_MAKEMASK(3,S_OHCI_TD_DI) |
| |
| #define | V_OHCI_TD_DI(x) _OHCI_MAKEVALUE(x,S_OHCI_TD_DI) |
| |
| #define | G_OHCI_TD_DI(x) _OHCI_GETVALUE(x,S_OHCI_TD_DI,M_OHCI_TD_DI) |
| |
| #define | K_OHCI_TD_NOINTR 7 |
| |
| #define | V_OHCI_TD_NOINTR V_OHCI_TD_DI(K_OHCI_TD_NOINTR) |
| |
| #define | S_OHCI_TD_DT 24 |
| |
| #define | M_OHCI_TD_DT _OHCI_MAKEMASK(2,S_OHCI_TD_DT) |
| |
| #define | V_OHCI_TD_DT(x) _OHCI_MAKEVALUE(x,S_OHCI_TD_DT) |
| |
| #define | G_OHCI_TD_DT(x) _OHCI_GETVALUE(x,S_OHCI_TD_DT,M_OHCI_TD_DT) |
| |
| #define | K_OHCI_TD_DT_DATA0 2 |
| |
| #define | K_OHCI_TD_DT_DATA1 3 |
| |
| #define | K_OHCI_TD_DT_TCARRY 0 |
| |
| #define | S_OHCI_TD_EC 26 |
| |
| #define | M_OHCI_TD_EC _OHCI_MAKEMASK(2,S_OHCI_TD_EC) |
| |
| #define | V_OHCI_TD_EC(x) _OHCI_MAKEVALUE(x,S_OHCI_TD_EC) |
| |
| #define | G_OHCI_TD_EC(x) _OHCI_GETVALUE(x,S_OHCI_TD_EC,M_OHCI_TD_EC) |
| |
| #define | S_OHCI_TD_CC 28 |
| |
| #define | M_OHCI_TD_CC _OHCI_MAKEMASK(4,S_OHCI_TD_CC) |
| |
| #define | V_OHCI_TD_CC(x) _OHCI_MAKEVALUE(x,S_OHCI_TD_CC) |
| |
| #define | G_OHCI_TD_CC(x) _OHCI_GETVALUE(x,S_OHCI_TD_CC,M_OHCI_TD_CC) |
| |
| #define | K_OHCI_CC_NOERROR 0 |
| |
| #define | K_OHCI_CC_CRC 1 |
| |
| #define | K_OHCI_CC_BITSTUFFING 2 |
| |
| #define | K_OHCI_CC_DATATOGGLEMISMATCH 3 |
| |
| #define | K_OHCI_CC_STALL 4 |
| |
| #define | K_OHCI_CC_DEVICENOTRESPONDING 5 |
| |
| #define | K_OHCI_CC_PIDCHECKFAILURE 6 |
| |
| #define | K_OHCI_CC_UNEXPECTEDPID 7 |
| |
| #define | K_OHCI_CC_DATAOVERRUN 8 |
| |
| #define | K_OHCI_CC_DATAUNDERRUN 9 |
| |
| #define | K_OHCI_CC_BUFFEROVERRUN 12 |
| |
| #define | K_OHCI_CC_BUFFERUNDERRUN 13 |
| |
| #define | K_OHCI_CC_NOTACCESSED 15 |
| |
| #define | K_OHCI_CC_CANCELLED 0xFF |
| |
| #define | OHCI_TD_MAX_DATA 8192 |
| |
| #define | OHCI_INTTABLE_SIZE 32 |
| |
| #define | OHCI_HCCA_ALIGN 256 /* Align on 256-byte boundary */ |
| |
| #define | _OHCI_REGIDX(x) ((x)*4) |
| |
| #define | R_OHCI_REVISION _OHCI_REGIDX(0) |
| |
| #define | R_OHCI_CONTROL _OHCI_REGIDX(1) |
| |
| #define | R_OHCI_CMDSTATUS _OHCI_REGIDX(2) |
| |
| #define | R_OHCI_INTSTATUS _OHCI_REGIDX(3) |
| |
| #define | R_OHCI_INTENABLE _OHCI_REGIDX(4) |
| |
| #define | R_OHCI_INTDISABLE _OHCI_REGIDX(5) |
| |
| #define | R_OHCI_HCCA _OHCI_REGIDX(6) |
| |
| #define | R_OHCI_PERIODCURRENTED _OHCI_REGIDX(7) |
| |
| #define | R_OHCI_CONTROLHEADED _OHCI_REGIDX(8) |
| |
| #define | R_OHCI_CONTROLCURRENTED _OHCI_REGIDX(9) |
| |
| #define | R_OHCI_BULKHEADED _OHCI_REGIDX(10) |
| |
| #define | R_OHCI_BULKCURRENTED _OHCI_REGIDX(11) |
| |
| #define | R_OHCI_DONEHEAD _OHCI_REGIDX(12) |
| |
| #define | R_OHCI_FMINTERVAL _OHCI_REGIDX(13) |
| |
| #define | R_OHCI_FMREMAINING _OHCI_REGIDX(14) |
| |
| #define | R_OHCI_FMNUMBER _OHCI_REGIDX(15) |
| |
| #define | R_OHCI_PERIODICSTART _OHCI_REGIDX(16) |
| |
| #define | R_OHCI_LSTHRESHOLD _OHCI_REGIDX(17) |
| |
| #define | R_OHCI_RHDSCRA _OHCI_REGIDX(18) |
| |
| #define | R_OHCI_RHDSCRB _OHCI_REGIDX(19) |
| |
| #define | R_OHCI_RHSTATUS _OHCI_REGIDX(20) |
| |
| #define | R_OHCI_RHPORTSTATUS(x) _OHCI_REGIDX(20+(x)) /* note: 1-based! */ |
| |
| #define | S_OHCI_REV_REV 0 |
| |
| #define | M_OHCI_REV_REV _OHCI_MAKEMASK(8,S_OHCI_REV_REV) |
| |
| #define | V_OHCI_REV_REV(x) _OHCI_MAKEVALUE(x,S_OHCI_REV_REV) |
| |
| #define | G_OHCI_REV_REV(x) _OHCI_GETVALUE(x,S_OHCI_REV_REV,M_OHCI_REV_REV) |
| |
| #define | K_OHCI_REV_11 0x10 |
| |
| #define | S_OHCI_CONTROL_CBSR 0 |
| |
| #define | M_OHCI_CONTROL_CBSR _OHCI_MAKEMASK(2,S_OHCI_CONTROL_CBSR) |
| |
| #define | V_OHCI_CONTROL_CBSR(x) _OHCI_MAKEVALUE(x,S_OHCI_CONTROL_CBSR) |
| |
| #define | G_OHCI_CONTROL_CBSR(x) _OHCI_GETVALUE(x,S_OHCI_CONTROL_CBSR,M_OHCI_CONTROL_CBSR) |
| |
| #define | K_OHCI_CBSR_11 0 |
| |
| #define | K_OHCI_CBSR_21 1 |
| |
| #define | K_OHCI_CBSR_31 2 |
| |
| #define | K_OHCI_CBSR_41 3 |
| |
| #define | M_OHCI_CONTROL_PLE _OHCI_MAKEMASK1(2) |
| |
| #define | M_OHCI_CONTROL_IE _OHCI_MAKEMASK1(3) |
| |
| #define | M_OHCI_CONTROL_CLE _OHCI_MAKEMASK1(4) |
| |
| #define | M_OHCI_CONTROL_BLE _OHCI_MAKEMASK1(5) |
| |
| #define | S_OHCI_CONTROL_HCFS 6 |
| |
| #define | M_OHCI_CONTROL_HCFS _OHCI_MAKEMASK(2,S_OHCI_CONTROL_HCFS) |
| |
| #define | V_OHCI_CONTROL_HCFS(x) _OHCI_MAKEVALUE(x,S_OHCI_CONTROL_HCFS) |
| |
| #define | G_OHCI_CONTROL_HCFS(x) _OHCI_GETVALUE(x,S_OHCI_CONTROL_HCFS,M_OHCI_CONTROL_HCFS) |
| |
| #define | K_OHCI_HCFS_RESET 0 |
| |
| #define | K_OHCI_HCFS_RESUME 1 |
| |
| #define | K_OHCI_HCFS_OPERATIONAL 2 |
| |
| #define | K_OHCI_HCFS_SUSPEND 3 |
| |
| #define | M_OHCI_CONTROL_IR _OHCI_MAKEMASK1(8) |
| |
| #define | M_OHCI_CONTROL_RWC _OHCI_MAKEMASK1(9) |
| |
| #define | M_OHCI_CONTROL_RWE _OHCI_MAKEMASK1(10) |
| |
| #define | M_OHCI_CMDSTATUS_HCR _OHCI_MAKEMASK1(0) |
| |
| #define | M_OHCI_CMDSTATUS_CLF _OHCI_MAKEMASK1(1) |
| |
| #define | M_OHCI_CMDSTATUS_BLF _OHCI_MAKEMASK1(2) |
| |
| #define | M_OHCI_CMDSTATUS_OCR _OHCI_MAKEMASK1(3) |
| |
| #define | S_OHCI_CMDSTATUS_SOC 16 |
| |
| #define | M_OHCI_CMDSTATUS_SOC _OHCI_MAKEMASK(2,S_OHCI_CMDSTATUS_SOC) |
| |
| #define | V_OHCI_CMDSTATUS_SOC(x) _OHCI_MAKEVALUE(x,S_OHCI_CMDSTATUS_SOC) |
| |
| #define | G_OHCI_CMDSTATUS_SOC(x) _OHCI_GETVALUE(x,S_OHCI_CMDSTATUS_SOC,M_OHCI_CMDSTATUS_SOC) |
| |
| #define | M_OHCI_INT_SO _OHCI_MAKEMASK1(0) |
| |
| #define | M_OHCI_INT_WDH _OHCI_MAKEMASK1(1) |
| |
| #define | M_OHCI_INT_SF _OHCI_MAKEMASK1(2) |
| |
| #define | M_OHCI_INT_RD _OHCI_MAKEMASK1(3) |
| |
| #define | M_OHCI_INT_UE _OHCI_MAKEMASK1(4) |
| |
| #define | M_OHCI_INT_FNO _OHCI_MAKEMASK1(5) |
| |
| #define | M_OHCI_INT_RHSC _OHCI_MAKEMASK1(6) |
| |
| #define | M_OHCI_INT_OC _OHCI_MAKEMASK1(30) |
| |
| #define | M_OHCI_INT_MIE _OHCI_MAKEMASK1(31) |
| |
| #define | M_OHCI_INT_ALL |
| |
| #define | S_OHCI_FMINTERVAL_FI 0 |
| |
| #define | M_OHCI_FMINTERVAL_FI _OHCI_MAKEMASK(14,S_OHCI_FMINTERVAL_FI) |
| |
| #define | V_OHCI_FMINTERVAL_FI(x) _OHCI_MAKEVALUE(x,S_OHCI_FMINTERVAL_FI) |
| |
| #define | G_OHCI_FMINTERVAL_FI(x) _OHCI_GETVALUE(x,S_OHCI_FMINTERVAL_FI,M_OHCI_FMINTERVAL_FI) |
| |
| #define | S_OHCI_FMINTERVAL_FSMPS 16 |
| |
| #define | M_OHCI_FMINTERVAL_FSMPS _OHCI_MAKEMASK(15,S_OHCI_FMINTERVAL_FSMPS) |
| |
| #define | V_OHCI_FMINTERVAL_FSMPS(x) _OHCI_MAKEVALUE(x,S_OHCI_FMINTERVAL_FSMPS) |
| |
| #define | G_OHCI_FMINTERVAL_FSMPS(x) _OHCI_GETVALUE(x,S_OHCI_FMINTERVAL_FSMPS,M_OHCI_FMINTERVAL_FSMPS) |
| |
| #define | OHCI_CALC_FSMPS(x) ((((x)-210)*6/7)) |
| |
| #define | M_OHCI_FMINTERVAL_FIT _OHCI_MAKEMASK1(31) |
| |
| #define | S_OHCI_FMREMAINING_FR 0 |
| |
| #define | M_OHCI_FMREMAINING_FR _OHCI_MAKEMASK(14,S_OHCI_FMREMAINING_FR) |
| |
| #define | V_OHCI_FMREMAINING_FR(x) _OHCI_MAKEVALUE(x,S_OHCI_FMREMAINING_FR) |
| |
| #define | G_OHCI_FMREMAINING_FR(x) _OHCI_GETVALUE(x,S_OHCI_FMREMAINING_FR,M_OHCI_FMREMAINING_FR) |
| |
| #define | M_OHCI_FMREMAINING_FRT _OHCI_MAKEMASK1(31) |
| |
| #define | S_OHCI_RHDSCRA_NDP 0 |
| |
| #define | M_OHCI_RHDSCRA_NDP _OHCI_MAKEMASK(8,S_OHCI_RHDSCRA_NDP) |
| |
| #define | V_OHCI_RHDSCRA_NDP(x) _OHCI_MAKEVALUE(x,S_OHCI_RHDSCRA_NDP) |
| |
| #define | G_OHCI_RHDSCRA_NDP(x) _OHCI_GETVALUE(x,S_OHCI_RHDSCRA_NDP,M_OHCI_RHDSCRA_NDP) |
| |
| #define | M_OHCI_RHDSCRA_PSM _OHCI_MAKEMASK1(8) |
| |
| #define | M_OHCI_RHDSCRA_NPS _OHCI_MAKEMASK1(9) |
| |
| #define | M_OHCI_RHDSCRA_DT _OHCI_MAKEMASK1(10) |
| |
| #define | M_OHCI_RHDSCRA_OCPM _OHCI_MAKEMASK1(11) |
| |
| #define | M_OHCI_RHDSCRA_NOCP _OHCI_MAKEMASK1(12) |
| |
| #define | S_OHCI_RHDSCRA_POTPGT 24 |
| |
| #define | M_OHCI_RHDSCRA_POTPGT _OHCI_MAKEMASK(8,S_OHCI_RHDSCRA_POTPGT) |
| |
| #define | V_OHCI_RHDSCRA_POTPGT(x) _OHCI_MAKEVALUE(x,S_OHCI_RHDSCRA_POTPGT) |
| |
| #define | G_OHCI_RHDSCRA_POTPGT(x) _OHCI_GETVALUE(x,S_OHCI_RHDSCRA_POTPGT,M_OHCI_RHDSCRA_POTPGT) |
| |
| #define | S_OHCI_RHDSCRB_DR 0 |
| |
| #define | M_OHCI_RHDSCRB_DR _OHCI_MAKEMASK(16,S_OHCI_RHDSCRB_DR) |
| |
| #define | V_OHCI_RHDSCRB_DR(x) _OHCI_MAKEVALUE(x,S_OHCI_RHDSCRB_DR) |
| |
| #define | G_OHCI_RHDSCRB_DR(x) _OHCI_GETVALUE(x,S_OHCI_RHDSCRB_DR,M_OHCI_RHDSCRB_DR) |
| |
| #define | S_OHCI_RHDSCRB_PPCM 16 |
| |
| #define | M_OHCI_RHDSCRB_PPCM _OHCI_MAKEMASK(16,S_OHCI_RHDSCRB_PPCM) |
| |
| #define | V_OHCI_RHDSCRB_PPCM(x) _OHCI_MAKEVALUE(x,S_OHCI_RHDSCRB_PPCM) |
| |
| #define | G_OHCI_RHDSCRB_PPCM(x) _OHCI_GETVALUE(x,S_OHCI_RHDSCRB_PPCM,M_OHCI_RHDSCRB_PPCM) |
| |
| #define | M_OHCI_RHSTATUS_LPS _OHCI_MAKEMASK1(0) |
| |
| #define | M_OHCI_RHSTATUS_OCI _OHCI_MAKEMASK1(1) |
| |
| #define | M_OHCI_RHSTATUS_DRWE _OHCI_MAKEMASK1(15) |
| |
| #define | M_OHCI_RHSTATUS_LPSC _OHCI_MAKEMASK1(16) |
| |
| #define | M_OHCI_RHSTATUS_OCIC _OHCI_MAKEMASK1(17) |
| |
| #define | M_OHCI_RHSTATUS_CRWE _OHCI_MAKEMASK1(31) |
| |
| #define | M_OHCI_RHPORTSTAT_CCS _OHCI_MAKEMASK1(0) |
| |
| #define | M_OHCI_RHPORTSTAT_PES _OHCI_MAKEMASK1(1) |
| |
| #define | M_OHCI_RHPORTSTAT_PSS _OHCI_MAKEMASK1(2) |
| |
| #define | M_OHCI_RHPORTSTAT_POCI _OHCI_MAKEMASK1(3) |
| |
| #define | M_OHCI_RHPORTSTAT_PRS _OHCI_MAKEMASK1(4) |
| |
| #define | M_OHCI_RHPORTSTAT_PPS _OHCI_MAKEMASK1(8) |
| |
| #define | M_OHCI_RHPORTSTAT_LSDA _OHCI_MAKEMASK1(9) |
| |
| #define | M_OHCI_RHPORTSTAT_CSC _OHCI_MAKEMASK1(16) |
| |
| #define | M_OHCI_RHPORTSTAT_PESC _OHCI_MAKEMASK1(17) |
| |
| #define | M_OHCI_RHPORTSTAT_PSSC _OHCI_MAKEMASK1(18) |
| |
| #define | M_OHCI_RHPORTSTAT_OCIC _OHCI_MAKEMASK1(19) |
| |
| #define | M_OHCI_RHPORTSTAT_PRSC _OHCI_MAKEMASK1(20) |
| |
| #define | M_OHCI_RHPORTSTAT_ALLC |
| |
| #define | beginningof(ptr, type, field) ((type *) (((int) (ptr)) - ((int) ((type *) 0)->field))) |
| |
| #define | OHCI_INTTREE_SIZE 63 |
| |
| #define | OHCI_EDPOOL_SIZE 128 |
| |
| #define | OHCI_TDPOOL_SIZE 64 |
| |
| #define | OHCI_RESET_DELAY 20 |
| |
